Selective and manual soldering, strand tinning
No Clean alcohol-based flux, Rework-Flux
Di-carboxylic acid complex, halide-free (WEEE/RoHS compliant)
Type ISO-9454: 2131 // DIN-EN 61190-1-1 (according to J-STD004) (IEC ORL0)
| Appearance: | colourless to light yellow liquid |
| Hazardous goods: | Yes |
| Solids content: | 4.0 wt.-% |
| Acid value: | 30 - 36 mg KOH/g |
| Halogenide-free: | Yes |
| Resinous: | No |
| Available as a concentrate: | No |
| Density at 20 °C: | 0.797 (+/- 0.003) g/ml |
| Flash point: | 12 °C |
| Durability: | 12 months |
This flux was developed for selective and manual soldering processes as well as strand tinning.
EO-RF-WB35 contains the activator system from our proven water-based flux: WB-35...-"System" (and other variants). It is applied using the special EO-Flux dosing bottle, but can also be applied using all standard application methods (except foaming). The solids content is 4 wt.-%. This flux is very versatile. Good results have been achieved in manual and selective soldering as well as in cable assembly/tinning. The generally applicable rule that the amount of flux applied should always be as low as possible also applies to this product
