Conventional soft soldering of copper materials, hot-dip metallizing, strip tinning, special applications
Liquid concentrate for the production of aqueous and alcoholic fluxes for tinning processes
Type ISO-9454: 2124 (WEEE/RoHS-compliant)
| Appearance: | Colorless to light yellow, transparent liquid |
| pH value: | 4 - 7 |
| Density at 20 °C: | 1.05 - 1.08 g/cm³ |
| Flash point: | 80 °C |
| Activators/resin: | organic hydrohalogen complex |
| Solvent: | Water |
| Bromide content [Br-]: | 9 - 11% |
| Durability: | 36 months |
EO-MC-001 is a liquid concentrate specially developed for tinning processes. The concentrate enables users to precisely match an alcohol-based or water-based flux to their process. EO-MC-001 is based on halogen-substituted organic compounds with high-performance additives for optimum wetting and, above all, offers a very wide operating temperature range (approx. 130 - 300 °C).
Recommendations for processing:
Depending on the process, the recommended application concentration is between 5 - 50% of EO-MC-001. For very complex tinning processes, it can also be used without additional dilution.
For electronics processes:
Water-based flux (classification according to J-STD-004: OR M1): Depending on the application, up to a maximum of 15% EO-MC-001 in DI water (deionized water) [approx. 50 g/l to 150 g/l].
Alcohol-based fluxes (classification according to J-STD-004: OR M1): Depending on application up to a maximum of 15% EO-MC-001 in isopropyl alcohol (propan-2-ol) [approx. 40 g/l to 120 g/l]. (Caution: Mixture is flammable, observe explosion protection)
- No dangerous goods according to the current transport regulations
- Coordination of an alcohol or water-based flux
