Solder paste

ZINNIN PQ Sn96.5Ag3Cu0.5

Recommended method of application

Conventional soft soldering of steel, stainless steel, iron, copper and brass materials

Cat. no. 0081
0081_EO_Zinnin-PQ-SN-96_EN_520x520px

Technical data

Metal alloy:Sn96.5Ag3.0Cu0.5
Particle size:< 80 μ
Metal portion:> 70 %
Flux type:3.1.2.A
Flux portion:< 30 %
Detection:UV-active
Durability:24 months

Customer added value

Solder paste for soft soldering of stainless steel, iron, copper and brass materials
Good handling, no dripping
No special solder feed necessary
Segregation by storage is indicated with colour, can be slightly homogenized by stirring
Very highly activated
Flux residues visible under UV light
Flux residues are easy to remove

Packaging units

Can: 300 g
Extras: Other packaging units on request
Product information: ZINNIN PQ Sn96.5Ag3Cu0.5
