Selective and manual soldering, strand tinning
No Clean-Flux, alcohol-based
Di-carboxylic acid complex, halogenide-free (WEEE/RoHS compliant)
Type ISO-9454: 2231 // DIN-EN 61190-1-1 (acc. to J-STD004) (IEC ORL0)
| Appearance: | colourless to light yellow liquid |
| Hazardous goods: | Yes |
| Solids content: | 4.0 wt.-% |
| Acid number: | 30 - 36 mg KOH/g |
| Halogenide-free: | Yes |
| Resiny: | No |
| Available as a concentrate: | No |
| Density at 20 °C: | 0.797 (+/- 0.003) g/ml |
| Flash point: | 12 °C |
| Durability: | 12 months |
This flux was developed for selective and manual soldering processes as well as strand tinning. EO-RF-G002 contains the activator system of our proven water-based flux: EO-G-002, Cat.-No. 6015. The application is carried out via the special EO-flux-dosage-bottle, but can also be carried out by all usual application methods (except foaming). The solid content is 4 wt.-%.
