Soldering of solar modules, tabber and stringer material and connecting of cells
No Clean-Flux especially for the solar industry
Carboxylic and di-carboxylic acid complex, halide-free, low solid content, highly activated (WEEE/RoHS compliant)
Type ISO-9454: 2231 // DIN-EN 61190-1-1 (acc. J-STD-004): ORL0
| Appearance: | colourless, clear liquid |
| Solids content: | 1.9 - 2.2 wt.-% |
| Density at 20 °C: | 0.793 - 0.800 g/ml |
| Acid value: | 0.793 +/- 0.003 mg KOH/g |
| Activators: | carboxylic and di-carboxylic acid complex, low solid content, highly activated |
| Halid content: | 0 % (halide-free) |
| Solvent: | short-chain alcohols |
| VOC: | 98 % |
| Flash point: | 12 °C |
| Durability: | 24 months |
| Available as a quick-drying version: | Yes |
EO-S-022 is a highly activated, halide-free formulated No Clean-Flux that has been specially developed for the requirements of the solar industry. It is ideal for soldering solar modules, tabber and stringer material as well as for connecting cells without leaving sticky residues.
The activators are specially designed for the production of solar modules. The solids content is 2%. EO-S-022 is totally free from corrosion action.
Recommendation from practice:
In general, flux should be applied in a minimal quantity.
